OVO E Endo Motor

This system brings advanced panoramic diagnostics into a modern dental practice environment. Equipped with a linear CMOS flat-panel sensor, dynamic automatic image-focusing, integrated touchscreen, and ergonomic patient positioning, the device supports a range of panoramic programmes (adult, child, sinuses, TMJ, bitewing) and optional one-shot cephalometric imaging. With a clean, minimalist design and upgrade pathways, it fits clinics where space is limited but quality cannot be compromised.

Product Features

• Dedicated linear sensor for the best image quality.

• Ambient lighting creates a comfortable atmosphere for the patient and allows for monitoring the unit status from a distance.

• Adult and, more importantly, child programs are crucial for ECO low dose examinations, allowing high diagnostic image quality for both overview and demanding diagnostic tasks.

• Latest sensor design, technology, and unit robotics have been used to achieve high precision level of detail and smooth, quiet operation. The machine allows for repeated exposures without having to wait.

Technical Specifications

Sensor Technology	CMOS Flat Panel, CSI Flat Panel for ceph
Pixel size	100 µm
Focal Spot	0.5 (IEC 336 / 1997)
Tube Voltage	60 - 86 kV
Tube Current	2.5 - 10 mA
Exposure time 2D	4.6 - 14.2 seconds
Exposure Time Ceph One-Shot	0,5s adult, 0,2s child
Ceph Image Size	240x300 mm
Weight	109kg without ceph, 137kg with ceph
Panoramic Programs	in total 9: adult pano, child pano, dentition, BW, TMJ, sinuses, half dentition left, half dentition right, anterior teeth.
Ceph Programs	LL 30x24, LL18x24, AP, PA, Carpus
Patient Sizes	Child, teenager, woman, man
Software	OrisWin DG Suite
Features	Panoramic, panoramic upgradable to 3D and ceph, panoramic with ceph upgradable to 3D.
Footprint	140x110 cm without CEPH, 240 x 110cm with CEPH
Patient position	Standing or sitting
Wheelchair acessible	Yes

Technical Drawing

Click here to download Catalogue

Features

Product Features

Technical Specifications

Click here to download Catalogue

• Made in UK and guaranteed accurate to ISO 81060-1
• Range 0–300mmHg, with the scale graduations starting at zero
• Clear white face with sharp black scale
• New flexible shock mount resists any damage to the gauge
• Fine red pointer gives precise indication
• Smaller, lighter and easily portable
• Weighted, 5x Castor Base
• Fitted with your choice of Velcro or Ambidex cuff
• Tough bright white ABS construction with built in carrying handle
• Lightweight ABS cuff container which is very easy to clean

• FreeFill - the newest filling system for liquid Denut's gutta-percha.
• Wireless - minimizing the time and materials needed to fill the channel.
• The use of the device ensures the highest quality and precision in filling the ducts.
• Wireless device 3-dimensional obturation system.
• Fantastic combination of filling with the method of vertical compaction.
• Provides excellent hermetic sealing of the root canal.
• Together, the entire main channel and side channels are filled.
• Excellent control of the honing part and filling of anatomically complex channels.
• Two mobile systems in one device (hot plugger and obturator).
• The obturator cover can be sterilized in an autoclave.
• The device is covered by the manufacturer's one-year warranty (application tips and tips for the plugger are consumable - they are not covered by the warranty).
• Technical data - charging system and batteries:
  • operating voltage - DC 3.7 V,
  • input adapter - AC 100 - 240 V, 50/60 Hz,
  • output - DC 7.5 V, 2.5 A,
  • indicator indicating the status of charging / charging,
  • time to full charge - about 1 hour,
  • two power supplies included.

• Gun - Obturation Gun:
  • heater - DC 3.7 V, 10 W,
  • temperature range - 1500C, 1800C, 2000C, 2200C (visible on the display),
  • working time with continuous use of the gun - about 120 minutes (when the battery is fully charged),
  • automatic shutdown after 5 minutes of non-use (battery saving),
  • automatic shut-off after 15 minutes of continuous operation (prevents burning of the heater),
  • ECO system (energy-saving) - temperature maintained at 1200C in order to warm up to a given temperature faster,
  • induction switch placed in the handle - switches the heating on / off depending on whether the device is held in hand or not,
  • the possibility of setting the needle in any direction (once the bent needle can be used to fill the lower or upper one).

• Plugger - obturation pen:
  • heater - DC 3.7 V, 10 W,
  • temperature range - 1500C, 1800C, 2000C, 2200C (visible on the display),
  • working time for continuous use of the plug - 60 minutes (when the battery is fully charged),
  • 3600 power button,
  • 6 directions of injection tips setting,
  • automatic shutdown after 5 minutes,
  • information about proper connection of the needle,
  • information about the damaged needle.

• Set contains:
  • gun - obturation gun - 1 piece,
  • gun stand with built-in charger - stand for gun - 1 piece,
  • plugger - obturation pen - 1 piece,
  • stand for plugger with built-in charger - stand for pen - 1 piece,
  • injection needles - gun needle - 3 pieces,
  • pen tip - pen tip - 4 pieces,
  • the key for injection needles - adapter - 1 piece,
  • pusher for hot gutta-percha - 2 pieces,
  • thermal casings - heat insulator - 2 pieces,
  • cleaning brush - brush - 1 piece,
  • power supply - 2 pieces,
  • gutta-percha - 20 pieces,
  • instruction - 1 piece.

• There is a possibility to buy tips for the plugger:
  • set - 4 sizes after the play,
  • size F - white (thin),
  • FM size - yellow,
  • size M - red,
  • ML size - black.
