Lace Up Wrist Splint

• Adaptable with most existing analog x-ray systems
• AED(Auto Exposure Detection) function available
• Simple and convenient installation
• Intuitive graphic user interface
• Over 1300 pre-loaded exam profiles with DRGEM’s generator
• Configurable automatic study
• PMS / EMR /HIS / RIS work list support
• Multiple printing formats
• DICOM 3.0 compliant
• Brightness and contrast adjustment
• Rotation
• Horizontal and vertical flip
• Zoom and pan
• Left / right makers
• Optimized work flow
• Automatic shutters
• Support DAP interface
• Exposure index (EI)
• DR upgrade solution by retrofit.
• Portable and Wireless FPD DR solution for maximum flexibility in virtually all general radiographic specialties.
• Portable and wireless detector fits into most existing analogue x-ray system.
• Faster workflow after DR upgrade.
• With AED(Auto Exposure Detection) function, there is no DR trigger cable between detector and generator providing very easy DR upgrade.
• Easy to interface with any kind of x-ray generator.
• Radmax acquisition workstation
• Turns any analogue X-Ray system into a fully DR system
• Optional image stitching program
• Vet software available
• Detector format: 17×17” / 17×14", wired/wireless

• TS-CSA-A (Vertical movement, 1.6m stroke, rail length 3x4meter) including HV cable 15m
• WBS-TA: Vertical movement

1. V Stroke:1,450mm in Uprigh Bucky Position,
2. 1,526mm in Horizontal Bucky position.

• PBT-4 is a 4 way Floating Tabletop. A large tabletop with extended travel enables all radiography studies with minimal patient movement. Fully fat tabletop without a frame on the edge makes cleanliness and odors free
• Digital Flat Panel Detector (FPD) – Wireless 17X14 (Csl, 4336W) with Auto Exposure Detection (AED) function, there is no DR trigger cable between detector and generator.
• Full Featured Imaging Software & Excellent Digital Image Processing:

1. Provides convenient user interface and easy operation
2. Anatomical view-based digital image processing automatically optimizes and enhances the quality of the captured image for the pictured anatomy.
3. Radiographic stand & automatic collimator control function
4. DICOM 3.0 networking interface includes Worklist, Print, Store, Query for integration with any PACS or RIS

• Included – Software, HP Laptop Computer

1. CPU≥3.2GHz
2. Memory capacity：≥4GB
3. Hard drive capacity ：≥500 GB
4. Resolution: 1280 x 1024
5. Display size： 21 inch color LCD screen
6. 64 bit Windows 10 operation system
7. Core: i5

• Power Rating - 32KW
• Generator - GXR-32S
• Rotor - Dual Speed Starter(DSS)
• Input Power - 400/480VAC, Three phase
• Line Frequency - 50/60Hz
• X-ray tube - DXT-12M, (0.6/1.2mm, 300kHU)
• Tube Voltage - 40 to 150kV, 1kV Step
• Tube Current – 10 to 640mA
• Output - 640mA@81kV,  500mA@104kV, 400mA@130kV, 320mA@150kV
• Time Range - 1ms to 10s
• mAs Range - 0.1 to 800mAs
• Reproducibility - Coe­cient of Variation : kV < 0.005, Time < 0.005,mAs < 0.01
• Accuracy - kV < ±(1%+1kV), mA < ±(3%+1mA), Time <±(1%+0.5ms), mAs < ±(3%+0.1mAs)
• Linearity - Coe­cient of Linearity < 0.01 : CL = (X1-X2)/(X1+X2), where X is mR/mAs
• Mechanical Parts:

1. V Stroke:1,450mm in Upright Bucky
2. Position, 1,526mm in Horizontal Bucky position.

Click Here To Download Catalogue

• Following spinal surgery
• Neck sprain or strain
• Cervical spondylosis

• Help to keep cervical spine in neutral
• Perforated splint with foam padding adds comfort and compliance
• Easy to adjust with hook and loop fasteners
