TEC2800 Tissue Embedding Center

Features of TEC2800 Tissue Embedding Center

• Large paraffin tank capacity: 6 liters
• The lamp brightness can be easily adjusted according to the ambient light brightness
• The large LCD screen is based on a user-friendly design
• The automated "Wake up" function can be easily programmed

• The extra-large working surface allows the pathologist to process more samples at one time
• The paraffin flow can be precisely controlled by the finger touch pad or the foot pedal
• The paraffin flow rate can be controlled by the knob
• The "built-in" forceps heating station can heat 6 forceps simultaneously
• The information LCD screen shows the current/setting temperature of the paraffin tank, left/right tray, platform surface, and forceps heating station, respectively
• The Peltier cold spot's temperature range is from ambient to -5℃

Specifications of TEC2800 Tissue Embedding Center

Features of TST1200 Grossing Station for Histopathology

• stainless steel housing
• low exhaust system
• cold and hot water system
• air sterilizing lamp and lighting
• Automatic induction-type hand dryer
• stainless steel table fitted with a lateral spray system, a washing sink, and a universal telescopic water tap
• pulverizer

Specifications of TST1200 Grossing Station for Histopathology

Features of AMR 400 Manual Rotary Microtome

• Spacious section waste tray
• Ergo-handwheel  handle
• Convenient storage area on top of the instrument
• Disposable blade holder with integrated safety finger protection guard
• Two handwheel locks: the handwheel can be locked at any position
• Distortion-resistant  base plate  ensures  optimum overall stability
• Both low & high-profile disposable blades are usable
• Two  types  of specimen clamp: standard specimen clamp  and“C” type specimen clamp
• Retraction  function:approx 220μm,could be deactivated
• Extremely smooth-running force  compensation system

Specifications of AMR 400 Manual Rotary Microtome

• Section thickness setting: Oμm～60μm adjustableOμm~2μm, in 0.5μm  increments;2μm～10μm, in 1μm   increments; 10μm~20μm, in 2μm  increments; 20μm～60μm, in 5μm increments;

• Trimming thickness:10,50μm  adjustable
• Retraction range:220 μm, could be deactivated
• Maximum specimen size:40×50×30 mm or standard cassette
• Specimen vertical stroke:59  mm
• Specimen horizontal stroke:28  mm
• Specimen holder adjusted system: Horizontal  orientation:±8°
•                                                                         Vertical orientation:±8°
• Blades  holder  base  repositioning(left-right):50mm
• Advanced feed  by rotating the left-hand wheel a circle around:0.275mm
• Dimensions: Width: 417 mm(276mm without handwheel)

Features of AST550 Fully-automatic Microtome Cryostat

• It is designed under engineering and ergonomic concepts. All the components are processed by computer numerical control.
• The retraction function prevents specimen damage from the blade.
• Total thickness calculation.
• Low temperature refrigeration system with environmentally friendly refrigerant R404.
• Adopt UV and O3 sterilization for 30 minutes every time.
• Peltier specimen clamp refrigeration may be turned on or off manually.
• Two defrosting methods: manual and automatic.
• Two running ways: manual and automatic.
• Emergency stop function: Press the red button to stop running when any emergency happens.
• The high precision unit is enclosed outside the cryostat chamber to prevent it from thermal expansion and contraction, and to keep a minimum maintenance requirement.
• An artificial intelligence interface is easy for users to learn and operate.
• LCD screen can display all information, including thickness, thickness sum, controlling time, temperature, timed on/off, and so on.
• Sleep Function: after activating this function, the temperature in the cryostat chamber can be kept between -1℃ and - 10℃; After stopping this function, the temperature in the freeze chamber will rise to working temperature within 30 minutes.
• Control panel with a locking function could avoid faulty operation.
• Handwheel locking function.
• Wide freezing shelf loads 8 specimen cassettes simultaneously, and two of them are equipped with a Peltier to meet different temperatures.

Specifications of AST550 Fully-automatic Microtome Cryostat

Features of AEC380 Tissue Embedding Center

• Easy to learn user interface with smart color touch screen.
• To meet high embedding work demand, the embedding platform can be arranged at both right and left sides with performance controlled separately, and process embedding work simultaneously.
• It adopts six heating ways and a precise temperature control system.
• The embedding module, cold spot, and paraffin trimmer are integrated.
• The paraffin flow can be released manually or by foot switch through an Electromagnetic valve.
• Forceps holder with constant temperature heating to have the residual wax drained automatically, effectively removes the paraffin adhering on the forcep tips.
• Embedding mold tray with a constant temperature helps to remove the wax adhering in the embedding mold, which facilitates the recycling of the embedding mold.
• The brightness of LED lights can be freely adjusted according to desired needs.
• The magnifier with a metal hose can be flexibly adjusted to the desired positions.
• Safe to work with. The use of non-metallic materials for areas in contact with hands avoids any discomfort caused by heating during embedding.

Specifications of AEC380 Tissue Embedding Center

Meet MDPC-8127, our ultra-high definition medical-grade display designed exclusively for digital pathology. With regulatory clearances as an IVD device (Europe and FDA) for use in digital pathology, including primary diagnosis, it’s the first display that you can confidently integrate into your digital pathology workflow with multiple whole slide imaging systems. Work with superior imaging technology and analyze your histological samples confidently, with unprecedented visual richness.

*In the USA, the MDPC-8127 can be used with WSI scanners and viewing software that have been validated for use with the display. The device may be used for primary diagnosis in the following validated FDA-cleared WSI systems and digital pathology viewing software:

Barco’s MDPC-8127 510(k) clearance:

• Philips Intellisite Pathology Solution with Philips Image Management System viewing software, cleared under K192259
• Philips Intellisite Pathology Solution with Paige.AI Inc. FullFocus DX viewing software, cleared under K201005
• Leica Aperio AT2 DX System with ImageScope DX viewing software, cleared under K190332
• Leica Aperio AT2 DX scanner with Sectra Digital Pathology Module, cleared under K193054

FDA- Cleared WSI systems and Digital Pathology Viewing Software with MDPC-8127:

• Hamamatsu NanoZoomer S360MD slide scanner system, cleared under K233027
• Leica Aperio GT 450 DX scanner with Aperio WebViewer DX, cleared under K232202
• Philips Intellisite Pathology Solution with JelloX MetaLite Dx Digital Pathology Software, cleared under K240303
• Philips IntelliSite Pathology Solution with Philips Image Management System and Galen™ Second Read™ AI, cleared under K241232
• Epredia E1000 Dx scanner with E1000 Dx IMS, cleared under K241717
• Hamamatsu NanoZoomer S360MD scanner with Lumea Viewer+, cleared under K242244

MDPC-8127 Validation protocol:

• Leica Aperio GT 450 DX scanner with Sectra Digital Pathology Module (3.3)
• Roche Ventana DP200 scanner with Roche uPath Enterprise Software
• Hamamatsu NanoZoomer S360MD Slide scanner with Proscia Concentriq® AP-Dx Digital Pathology software

The MDPC-8127 has been subjected to Barco’s ecoscoring protocol and has received an A+ rating. Some key factors that contributed to this rating are:

• High energy efficiency
• Possibility to switch to standby mode when the device is not in use
• Use of halogen-free materials on all levels: cables, PCBs, plastics
• The number of screws and screw types is reduced significantly to improve ease of disassembly
• Unpainted large plastic parts

Features

A proven formula

Ultra-high definition

Constant quality
