Mini MIRI Dry Incubator

Brands: Esco Medical

~~$0.00~~

Shipped From Abroad

The Mini MIRI^® Dry incubator is a two-chamber mini bench-top incubator that takes after the classic MIRI^® Multiroom incubator. This mini version of the MIRI^® is a perfect fit for IVF laboratories that prioritize footprint and affordability.

Delivery & Availability:
Typically 10-21 working days – excluding furniture and heavy/bulky equipment. Please contact us for further information.

Brands:: Esco Medical

Description
Reviews (0)

Description

Recirculating Gas for Minimal Gas Consumption

The Mini MIRI® Dry Incubator is a dry IVF bench-top incubator that can recirculate gas inside the incubator and is compatible with a VOC/HEPA filtration system, unlike other humidified IVF incubators. Gas inserts (whether pure N₂ and CO₂ or premixed gas) first go through the tri-gas mixing chamber to achieve the set CO₂ and O₂ gas concentrations by the user, and then into the VOC/HEPA filter before entering the incubator chambers. After this, gas now enters a UV Sterilization (254nm) table before going back to the tri-gas mixing chamber and recirculating the gas. This system ensures that there is minimal gas consumption even with lid openings of the incubator chambers while maintaining the recirculating air clean and safe for the embryo samples.

Data Logger Software

The Mini MIRI^® Dry Incubator comes with data logger software that monitors the temperature, gas concentration, gas input pressure, gas flow rates, and alarms. All real-time parameters can be viewed conveniently in graphs when the Mini MIRI^® is connected to a PC, and the data logger software can also monitor multiple incubators at the same time. Weekly reports can be exported for the users’ convenience.

Specifications

Overall Dimensions (W x D x H)	525 x 420 x 230 mm (22.7 x 16.5 x 9″)
Weight	22 kg (48.5 lbs)
Material	Mild steel / Aluminum / PET / Stainless steel
Power Supply	115V 60Hz or 230V 50Hz
Power Consumption	160 W
Temperature Control Range	24.9 – 40 °C
*CO₂ Gas Consumption	<2 Liters per hour
**N₂ Gas Consumption	<8 Liters per hour
Gas Input Pressure	0.4 to 0.6 bar (5.80 – 8.70 PSI)
Operating Altitude	Up to 2000 meters (6560 feet or 80kPa – 106kPa)
Shipping Weight	30 kg (66.1 lbs) (Including the pallet’s weight)
Shipping Dimensions	630 x 525 x 500 mm (24.8 x 20.7 x 19.7″) (device on the pallet)
