JAY-1000 Portable Oxygen Concentrator

The Longfian JAY-1000P is an advanced portable oxygen concentrator designed for patients requiring reliable oxygen therapy during travel or daily activities. With a weight of 1.98 kg and dimensions of 183×86×199 mm, it combines portability with high performance.​

This device offers pulse dose delivery with five adjustable flow settings (1–5), ensuring precise oxygen delivery tailored to individual needs. It maintains an oxygen concentration of 93% ± 3%, supporting effective respiratory therapy.​

The JAY-1000P features a user-friendly LCD display and intuitive controls, enhancing the user experience. Its 12-cell battery provides up to 5.5 hours of operation on flow setting 1, making it ideal for extended use. The device is CE and ISO 9001 certified, ensuring compliance with international quality standards.​

Key Features:

• Pulse Dose Delivery: Five flow settings (1–5) for customized therapy.

• High Oxygen Concentration: Maintains 93% ± 3% purity.

• Lightweight and Compact: 1.98 kg and 183×86×199 mm for portability.

• Extended Battery Life: Up to 5.5 hours on flow setting 1.

• User-Friendly Interface: LCD display with simple controls.

• Certifications: CE and ISO 9001 certified for quality assurance.

• Portability: Includes a durable shoulder bag for easy transport.

Features

• Individual dosage of the provocation material

• All-in-one measurement, high automation

Main Function

• Complete Spirometry (Slow VC, FVC, Flow-Volume Loop, Tidal breathing analysis, MVV)
• Bronchial dilation test （pre/post dilator)
• Bronchial provocation test

The JAY-3AW and JAY-5AW are robust oxygen concentrators designed for continuous use. With flow rates of 3L/min and 5L/min, they deliver oxygen at a concentration of 93% (±3%). Their innovative cooling systems ensure reliable 24/7 operation, making them suitable for both home and clinical environments.​

Key features include:

• User-Friendly Interface: Simple controls with an easy-to-read LCD display.

• Mobility: Four flexible castors with two brakes for easy movement and secure positioning.

• Safety Features: Humidifier bottle with a 6PSI pressure relief valve, and alarms for power failure, high/low pressure, and low oxygen concentration.​

These models are compatible with High-Flow Nasal Cannula (HFNC), Hyperbaric Oxygen Chambers (HBOC), and BIPAP systems, enhancing their versatility in oxygen therapy applications. ​

Key Features:

• Flow Rate: 0.5–5 L/min
• Oxygen Concentration: 93% ± 3%
• Quiet Operation: ≤40 dB noise level
• Compact Design: Easy to place in various settings
• User-Friendly Interface: Simple controls for ease of use
• Safety Alarms: Power failure, high/low pressure, and low oxygen concentration alerts​

The Longfian JAY-1000 is a lightweight and compact portable oxygen concentrator designed for individuals requiring supplemental oxygen therapy on the go. Weighing only 1.5 kg and measuring 193×83×173 mm, it offers enhanced mobility without compromising performance.​

Equipped with pulse dose delivery, the JAY-1000 provides oxygen flow settings from 1 to 5, ensuring efficient oxygen delivery tailored to the user's needs. It delivers medical-grade oxygen at a concentration of 93% ± 3%, supporting optimal respiratory function.​medzell.net

The device features an easy-to-remove external battery with a duration of up to 3 hours, allowing users to maintain their active lifestyles without interruption. Its user-friendly interface and comfortable shoulder bag enhance usability and portability.​

Key Features:

• Pulse Dose Delivery: Five flow settings (1–5) for personalized oxygen therapy.
• High Oxygen Concentration: Delivers 93% ± 3% purity.
• Lightweight Design: Only 1.5 kg for enhanced mobility.
• Compact Dimensions: 193×83×173 mm for easy transport.
• Battery Life: Up to 3 hours of operation.
• User-Friendly Interface: Simple controls for ease of use.
• Portability: Includes a strong, comfortable shoulder bag.

The Longfian JAY-10FW is a high-capacity, dual-flow oxygen concentrator designed to meet the needs of patients requiring substantial oxygen support. With a flow rate adjustable from 0.5 to 10 L/min and oxygen concentration maintained at 93% ± 3%, it ensures effective therapy for conditions like pulmonary fibrosis and severe COPD. The dual-flow configuration allows two users to inhale oxygen simultaneously, enhancing its utility in clinical settings. Equipped with advanced cooling technology, the JAY-10FW ensures reliable 24/7 operation. Its user-friendly LCD display, safety alarms, and mobility features enhance usability and patient safety.​

Key Features:

• Flow Rate: 0.5–10 L/min

• Oxygen Concentration: 93% ± 3%

• Dual-Flow Capability: Supports two users simultaneously

• Continuous Operation: Advanced cooling system for 24/7 use

• User-Friendly Interface: LCD display with simple controls

• Mobility: Four castors with two brakes for easy movement

• Safety Alarms: Power failure, high/low pressure, and low oxygen concentration alerts
